This FAG B7020-E-T-P4S-UL bearing is a super precision angular contact ball bearing with a 25° contact angle and a phenolic cage, it has a universal design and is suitable for high speeds. FAG is a renowned bearing brand offering high-quality products for industrial applications. This bearing is ideal for machine tool spindles, electric motors and other precision applications.

Description / FAG B7020-E-T-P4S-UL, Spindle bearing, 4012801210218, 100x150x24, B7020ETP4SUL

B spindle bearing with large steel balls, Main specifications, Also known as, 0191525230000, 7020ACDGA/P4A, Category, Angular Contact Ball Bearing Single Row, Weight and Dimensions: Inner (d) MM, 100, Outer (D) MM, 150, Width (B) MM, 24, Weight (kg), 1.23: Product Properties, Seal, No Seal, Cage Type, TB - Hard Fiber Cage, Precision, P4S Precision (Higher than P4), Contact Angle, 25 degrees, Pairing, G - Universal Pairing, Axial Internal Clearance / Preload, UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements, Lubrication, Standard Lubrication, Data from Schaeffler (medias), Radial Static Load Rating C0r (N), 55000, Radial Dynamic Load Rating Cr (N), 79000, ECLASS number, 23-05-08-03, ECLASS2 number, 23-05-08-03, Medias description, Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances, Suffix description, E, 25° Contact Angle, T, Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C, P4S, Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9, UL, Single Bearing, Universal, Light Preload FAG B7020-E-T-P4S-UL is a high precision angular contact ball bearing for industrial applications. This FAG bearing is suitable for universal matching and can be used in various operations. It has an optimized internal construction and can be purchased from PLC2Day.

More Information

Item Number B7020-E-T-P4S-UL
Brands FAG
HS Code Upon Request
EAN 4.0128E+12
Manufacturer FAG
Product Condition New
Packing Condition Original Packing
