VMPA2B8R2C2C06, Regulator Plate: GTIN: 4052568190378, Serie: J802/J702, Features: Construction width 21 mm, Mounting position optional, Vertical pneumatic linkage Pressure regulator for 2, Controller function Output pressure constant, With secondary venting, Symbol 00992003, Selection of pressure gauge Possible, Pressure regulation range 2 bar ... 6 bar, Inlet pressure 1 0.5 bar ... 10 bar, Operating medium Compressed air to ISO 8573-1:2010 [7:4:4], Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required), Corrosion resistance class CRC 1 - Low corrosion stress, LABS (PWIS) conformity VDMA24364-B1/B2-L, Degree of protection IP65, To IEC 60529, Ambient temperature -5 °C ... 50 °C, Max. tightening torque 0.65 Nm, Product weight 180 g, Mounting with vertical stacking On manifold sub-base, Pressure gauge connection Via retaining clamp, Note on materials RoHS-compliant, Material control panel PA, Material seals NBR, Material regulator housing PA.
